plastic bottle making machine

plastic bottle making machine
plastic bottle making machine

Large Image :  plastic bottle making machine

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: US $30,000-50,000 / Sets
Packaging Details: Standard export packing
Supply Ability: 30 Set/Sets per Year

plastic bottle making machine

Description
Max.container Capacity: 20-30L Number Of Die: 1 SET
Machine Dimension LXWXH: 4.8x2.5x4M Machine Weight: 14ton
Clamping Tonnage: 200kn Platen Opening Stoke: 400-900mm
Toggle Stroke: 500mm Max Mould Size(W*H): 600*100mm
Screw Diameter: 85mm Screw L/D Ratio: 24L/D
High Light:

bottle filling machine

,

water filling machine





        SPECIFICATIONS



  Max.container capacity       L              20-30L



  Number of die              set                1



  Machine dimension LXWXH  M            4.8x2.5x4



  Machine weight             ton              14



                 Clamping unit



  Clamping tonnage           kn              200



  Platen opening stoke         mm           400-900



  Toggle stroke               mm            500



   Max mould size(W*H)       mm          600*1000



                  Extruder unit



  Screw diameter             mm             85



  Screw L/D ratio             L/D             24



(HDPE)Plasticising capacity         Kg/h            130





Number of heating zone      zone             4



  Extruder heading power      kw              20



  Extruder fan power          kw              0.5



  Extruder driving power       kw              30







                     Die



  Max accumulate capacity         L            4.7



  max extrusion speed           kg/sec          1.8



  Number of heating zone     zone             4



  Power of die heating        kw              13.5



  max die-pin diameter       mm              350



  parison control point      number           30



  die head forward and backward stroke  mm     450



  parison contril hydraulic pump power KW           4



                     Power



  Total power                kw            115



  Pump driver power          kw             45



   Air pressure                Mpa           1



   Average energy consumption  kw             50



   Compressed air             m3/min          1.5



   Cooling water              m3/minv         0.4







        up-blowing equipment



  exceed strole              mm             170-450



  up and down stroke           mm           150



  pre-clip max distance          mm            210







                  ROBOT



clip stroke              mm            250



take-away stroke         mm            1000







Platen up and down stroke        mm             390



speed                   mm/min         30

    plastic bottle making machine 0



NO.

PARTS NAME

ORIGIN

1

COMPUTER CONTROL SYSTEM

TAIWAN

2

OIL PUMP

USA

3

HYDRAULIC VALVE

USA

4

INVERTER

TAIWAN

6

STROKE SWITCH

GERMANY

7

POSITION TRANSDUCER

GERMANY

8

PNEUMATIC VALVE

GERMANY

9

SEAL RING

JAPAN

10

GEAR BOX

CHINA

11

PARISON CONTROL

USA

12

AUTOMATIC LUBRICATION

CHINA

13

SCREW&BARREL

CHINA
